Unitree Z1 Overview
The Unitree Z1 is a six-axis lightweight robot arm that weighs 4.5 kg as the Z1 Pro, with a payload of 3 kg or more, a 740 mm reach and repeatability of about 0.1 mm.
Key Specifications
Specification | Unitree Z1 |
Manufacturer | Unitree Robotics |
Model | Z1 Pro |
Category | Robot arm / Six-axis lightweight robot arm |
Degrees of freedom | Z1 AIR: 6; Z1 PRO: 6 |
Weight | Z1 AIR: 4.3 kg; Z1 PRO: 4.5 kg |
Payload | Z1 AIR: 2 kg; Z1 PRO: 3 kg or more |
Reach | Z1 AIR: 740 mm; Z1 PRO: 740 mm |
Repeatability | Z1 AIR: About 0.1 mm; Z1 PRO: About 0.1 mm |
Power supply | Z1 AIR: 24 V, more than 20 A; Z1 PRO: 24 V, more than 20 A |
Maximum power | Z1 AIR: 500 W; Z1 PRO: 500 W |
Control | Z1 AIR: Position and force control; Z1 PRO: Position and force control |
Price | From USD 15,999 |
Prices are indicative, are not final and may change.
Applications
Mobile Manipulation
Research and Development
Service and Logistics
Unitree Z1 Review Summary
The Z1 is built to ride on other robots. At 4.5 kg it is light enough to be carried by a quadruped robot, and it runs from a 24 V supply. It has force control and collision detection in every joint and an open programming interface on Ubuntu. Its accuracy of about 0.1 mm is adequate for manipulation research, and the maker itself warns that the low gear ratios can cause position error and shaking unless the control is tuned. It is a research and development arm, not a factory cobot. When this review was written the maker's shop listed the Z1 Pro as backordered.
Pros
4.5 kg weight with a 740 mm reach
Force control and collision detection in every joint
24 V supply suits battery-powered robots
Open programming on Ubuntu
Joint speed of 180°/s
Cons
Payload of 2 to 3 kg
High price for the payload
Backordered at the time of writing
Who It Is For
The Z1 fits research groups and developers who need a light, force-controlled arm for a mobile robot.
