OnRobot Screwdriver Overview
The OnRobot Screwdriver is an electric screwdriving tool with a torque range of 0.15 to 5 Nm, an output speed of up to 340 RPM and an integrated z-axis with a 55 mm shank stroke. It is designed for automated assembly with screws from M1.6 to M6 and up to 50 mm long, and its own axis movement means the robot only has to position the tool over the hole. Torque accuracy is 0.04 Nm below 1.33 Nm and 3 % above that. The tool weighs 2.5 kg, is rated IP54 and runs on 24 V DC with a current draw of up to 4.5 A.
Key Specifications
Specification | OnRobot Screwdriver |
Manufacturer | OnRobot |
Model | Screwdriver |
Category | End effector / Screwdriving tool |
Axes (DoF) | end effector |
Price | From USD 11,600 |
Prices are indicative, are not final and may change.
Applications
Robot end-of-arm tooling
Gripping
Machine tending
Assembly
Packaging
Industries
Automotive · Electronics · Metalworking · Plastics · Food and beverage · Pharmaceuticals · Logistics
Technical Details
Electric screwdriver with integrated z-axis
Torque 0.15–5 Nm
Torque accuracy 0.04 Nm below 1.33 Nm, 3 % above
Output speed up to 340 RPM
Screws M1.6–M6
Shank stroke 55 mm
Screw length up to 50 mm (35 mm within full safety)
Weight 2.5 kg
IP54
24 V DC (20–25 V), 75–4500 mA
OnRobot Screwdriver Review Summary
The OnRobot Screwdriver is an electric screwdriving tool with a torque range of 0.15 to 5 Nm, an output speed of up to 340 RPM and an integrated z-axis with a 55 mm shank stroke. It is designed for automated assembly with screws from M1.6 to M6 and up to 50 mm long, and its own axis movement means the robot only has to position the tool over the hole. Torque accuracy is 0.04 Nm below 1.33 Nm and 3 % above that. The tool weighs 2.5 kg, is rated IP54 and runs on 24 V DC with a current draw of up to 4.5 A. It is listed from USD 11,600.
Pros
IP54
Cons
Compatibility with the robot and controller must be confirmed before ordering
Mounting, cabling and integration are quoted separately
Who It Is For
The OnRobot Screwdriver fits manufacturers who want to automate screwdriving and fastening.
