Yaskawa Motoman SP80 Overview

The Yaskawa Motoman SP80 is a 6-axis spot welding robot with a maximum payload of 80 kg, a horizontal reach of 2236 mm and a repeatability of ±0.03 mm. It belongs to Yaskawa's SP series of spot welding robots, which use an integrated spot harness and fast axis acceleration to cut non-welding time. The arm weighs 630 kg and is installed on the floor, wall, ceiling or tilted, and it runs on the YRC1000 controller.

Key Specifications

Prices are indicative, are not final and may change.

Applications

• Arc welding

• Spot welding

• Cutting

• Material handling

• Machine tending

Industries

Automotive · Electronics · Metalworking · Plastics · Food and beverage · Pharmaceuticals · Logistics

Technical Details

• 6 controlled axes

• Max. payload 80 kg

• Horizontal reach 2236 mm

• Repeatability ±0.03 mm

• Mass 630 kg

• Installation floor, wall, ceiling, tilted

• Controller YRC1000

Yaskawa Motoman SP80 Review Summary

The Yaskawa Motoman SP80 is a 6-axis spot welding robot with a maximum payload of 80 kg, a horizontal reach of 2236 mm and a repeatability of ±0.03 mm. It belongs to Yaskawa's SP series of spot welding robots, which use an integrated spot harness and fast axis acceleration to cut non-welding time. The arm weighs 630 kg and is installed on the floor, wall, ceiling or tilted, and it runs on the YRC1000 controller. It is listed from USD 50,000.

Pros

• 80 kg maximum payload with a 2236 mm reach

• ±0.03 mm repeatability

• Several installation options: floor, wall, ceiling, tilted

• Wide choice of industrial fieldbus interfaces

Cons

• Needs safety fencing or equivalent safeguarding

• The 80 kg maximum payload includes the end effector

• End effectors, safety equipment and integration are quoted separately

Who It Is For

The Yaskawa Motoman SP80 fits automotive and sheet-metal manufacturers that are automating spot welding and heavy handling.
