SMC LEHZ Overview
The SMC LEHZ is a compact two-finger parallel electric gripper with an opening/closing stroke of 4 to 30 mm, a gripping force of 6 N to 210 N across the six body sizes (10, 16, 20, 25, 32 and 40) and a repeatability of ±0.02 mm. It is designed for general pick-and-place and assembly work where gripping force, speed and finger position need to be set per workpiece, at up to 64 points. Compact versions of sizes 10 to 25 deliver 2 N to 28 N. The gripper weighs between 135 g and 1,760 g, is driven by a 24 VDC step motor with servo control and operates at 5 to 40 °C. It is run from an SMC step motor controller with parallel I/O or a fieldbus connection.
Key Specifications
Specification | SMC LEHZ |
Manufacturer | SMC |
Model | LEHZ |
Category | End effector / Gripper |
Repeatability | ±0.02 mm |
Speed | 5 to 120 mm/s |
Controller | SMC JXC series, LECP1 or LECPA step motor controller |
Interfaces | Parallel I/O; EtherCAT; EtherNet/IP; PROFINET; DeviceNet; IO-Link; CC-Link |
Price | From USD 940 |
Prices are indicative, are not final and may change.
Applications
Robot end-of-arm tooling
Gripping
Machine tending
Assembly
Packaging
Industries
Automotive · Electronics · Metalworking · Plastics · Food and beverage · Pharmaceuticals · Logistics
Technical Details
Electric (24 VDC step motor, servo)
2 fingers, parallel
Body sizes 10 / 16 / 20 / 25 / 32 / 40
Stroke 4 / 6 / 10 / 14 / 22 / 30 mm
Gripping force 6 to 210 N (basic), 2 to 28 N (compact)
Opening/closing speed 5 to 120 mm/s
Weight 135 to 1,760 g
5 to 40 °C
SMC LEHZ Review Summary
The SMC LEHZ is a compact two-finger parallel electric gripper with an opening/closing stroke of 4 to 30 mm, a gripping force of 6 N to 210 N across the six body sizes (10, 16, 20, 25, 32 and 40) and a repeatability of ±0.02 mm. It is designed for general pick-and-place and assembly work where gripping force, speed and finger position need to be set per workpiece, at up to 64 points. Compact versions of sizes 10 to 25 deliver 2 N to 28 N. The gripper weighs between 135 g and 1,760 g, is driven by a 24 VDC step motor with servo control and operates at 5 to 40 °C. It is run from an SMC step motor controller with parallel I/O or a fieldbus connection. It is listed from USD 940.
Pros
Repeatability: ±0.02 mm
Speed: 5 to 120 mm/s
Gripping force 6 to 210 N (basic), 2 to 28 N (compact)
Wide choice of communication interfaces
Cons
Compatibility with the robot and controller must be confirmed before ordering
Mounting, cabling and integration are quoted separately
Who It Is For
The SMC LEHZ fits robot users and integrators who need a gripper for handling, machine tending or assembly.
