FANUC iRVision 3DV/1600 Overview

The FANUC iRVision 3DV/1600 is the largest sensor in the 3DV family of 3D vision sensors. It captures up to 1104 x 960 3D points with a single projected light pattern across a measurement volume 2000 mm deep that widens from 1245 x 1178 mm to 3203 x 2797 mm. The sensor weighs 3.2 kg, is IP67 protected and works either fixed above the cell or mounted on the robot. It is designed for bin picking, depalletizing and line tracking of large parts.

Key Specifications

Prices are indicative, are not final and may change.

Applications

• Robot end-of-arm tooling

• Gripping

• Machine tending

• Assembly

• Packaging

Industries

Automotive · Electronics · Metalworking · Plastics · Food and beverage · Pharmaceuticals · Logistics

Technical Details

• 3D vision sensor measuring with a single projected light pattern

• Up to 1104 x 960 3D points

• Measurement range 1245 x 1178 x 2000 mm (W1 x D1 x H) and 3203 x 2797 mm (W2 x D2)

• Blue LED for 2D detection

• Dimensions 234 x 198.2 x 70 mm

• Mass 3.2 kg

• Protection IP67

• Robot-mountable

• Controllers R-30iB Plus, R-30iB Mate Plus, R-30iB Compact Plus and R-30iB Mini Plus

FANUC iRVision 3DV/1600 Review Summary

The FANUC iRVision 3DV/1600 is the largest sensor in the 3DV family of 3D vision sensors. It captures up to 1104 x 960 3D points with a single projected light pattern across a measurement volume 2000 mm deep that widens from 1245 x 1178 mm to 3203 x 2797 mm. The sensor weighs 3.2 kg, is IP67 protected and works either fixed above the cell or mounted on the robot. It is designed for bin picking, depalletizing and line tracking of large parts. It is listed from USD 15,000.

Pros

• Made by FANUC for FANUC robots

• Protection IP67

Cons

• Designed for FANUC robots only

• Installation and integration are quoted separately

Who It Is For

The FANUC iRVision 3DV/1600 fits FANUC robot users who need to add a robot vision system to a cell.
