KUKA KR FORTEC KR 420 Overview
The KUKA KR FORTEC KR 420 is a 6-axis heavy-duty industrial robot with a payload of 420 kg and a maximum reach of 3100 mm. It is designed for heavy-duty handling, machining and spot welding of large, heavy components. It is installed on the floor and runs on the KUKA KR C5 controller.
Key Specifications
Specification | KUKA KR FORTEC KR 420 |
Manufacturer | KUKA |
Model | KR FORTEC KR 420 |
Category | Robot arm / Industrial 6-axis robot |
Payload | 420 kg |
Reach | 3100 mm |
Axes (DoF) | 6 |
Controller | KUKA KR C5 |
Interfaces | PROFINET; PROFIsafe; EtherNet/IP; CIP Safety; EtherCAT; PROFIBUS; DeviceNet; Ethernet; digital I/O 24 V |
Certifications | ISO 10218-1; ISO 13849-1 Cat. 3 / PL d; UL/CSA |
Price | From USD 104,000 |
Prices are indicative, are not final and may change.
Applications
Material handling
Machine tending
Assembly
Packaging
Inspection
Dispensing
Industries
Automotive · Electronics · Metalworking · Plastics · Food and beverage · Pharmaceuticals · Logistics
Technical Details
6 axes
Payload 420 kg
Reach 3100 mm
Mounting floor
Controller KR C5
KUKA KR FORTEC KR 420 Review Summary
Shortlist the KR FORTEC KR 420 when payload, reach and installation layout fit the cell. Validate tool and workpiece load, cycle time, environment, access and full installed cost.
