KUKA KR 10 R900-2 Overview
The KUKA KR 10 R900-2 is a 6-axis compact industrial robot with a payload of 11 kg, a maximum reach of 901 mm and a pose repeatability of ±0.02 mm. It is designed for fast handling, assembly and machine tending in tight cells, and its IP65/IP67 protection suits it to dusty or wet surroundings. The robot weighs about 55 kg, is installed on the floor, ceiling or wall or at an angle and runs on the KUKA KR C5 micro controller.
Key Specifications
Specification | KUKA KR 10 R900-2 |
Manufacturer | KUKA |
Model | KR 10 R900-2 |
Category | Robot arm / Industrial 6-axis robot |
Payload | 11 kg |
Reach | 901 mm |
Repeatability | ±0.02 mm |
Axes (DoF) | 6 |
Controller | KUKA KR C5 micro |
Interfaces | PROFINET; PROFIsafe; EtherNet/IP; CIP Safety; EtherCAT; Ethernet; 16 digital inputs / 16 digital outputs |
Certifications | ISO 10218-1; ISO 13849-1 Cat. 3 / PL d; UL/CSA |
Price | From USD 30,000 |
Prices are indicative, are not final and may change.
Applications
Material handling
Machine tending
Assembly
Packaging
Inspection
Dispensing
Industries
Automotive · Electronics · Metalworking · Plastics · Food and beverage · Pharmaceuticals · Logistics
Technical Details
6 axes
Payload 11 kg
Reach 901 mm
Repeatability ±0.02 mm
Weight 55 kg
Mounting floor, ceiling, wall, angle
Controller KR C5 micro
KUKA KR 10 R900-2 Review Summary
Shortlist the KR 10 R900-2 when its payload, reach and installation layout fit your cell. Validate full tool and workpiece load, cycle time, environment, access and installed cost.
