Robotiq Hand-E C10 Overview

The Robotiq Hand-E C10 is a concentric three-finger electric gripper with a 40 mm diameter stroke, a closing force of 25 to 175 N per finger and a payload of 10 kg. It is designed for centring and holding round parts in CNC machine tending. Closing speed ranges from 14 to 107 mm/s and fingertip position resolution is 0.08 mm. The gripper weighs 1.5 kg and is rated IP67.

Key Specifications

Prices are indicative, are not final and may change.

Applications

• Robot end-of-arm tooling

• Gripping

• Machine tending

• Assembly

• Packaging

Industries

Automotive · Electronics · Metalworking · Plastics · Food and beverage · Pharmaceuticals · Logistics

Technical Details

• Concentric three-finger electric gripper

• Stroke 40 mm (diameter)

• Closing force 25 to 175 N per finger

• Total grip force 40 to 525 N

• Payload 10 kg

• Closing speed 14 to 107 mm/s

• Fingertip position resolution 0.08 mm

• Weight 1.5 kg

• IP67

Robotiq Hand-E C10 Review Summary

The Robotiq Hand-E C10 is a concentric three-finger electric gripper with a 40 mm diameter stroke, a closing force of 25 to 175 N per finger and a payload of 10 kg. It is designed for centring and holding round parts in CNC machine tending. Closing speed ranges from 14 to 107 mm/s and fingertip position resolution is 0.08 mm. The gripper weighs 1.5 kg and is rated IP67. It is listed from USD 7,200.

Pros

• Payload: 10 kg

• Repeatability: 0.08 mm fingertip position resolution

• Speed: 14 to 107 mm/s closing speed

• Total grip force 40 to 525 N

• IP67

Cons

• Compatibility with the robot and controller must be confirmed before ordering

• Mounting, cabling and integration are quoted separately

Who It Is For

The Robotiq Hand-E C10 fits robot users and integrators who need a gripper for handling, machine tending or assembly.

Full review: Robotiq Hand-E C10 Review: Specs, Price and Applications
