Piab piSOFTGRIP 50 Overview
The Piab piSOFTGRIP 50 is a vacuum-driven soft gripper for objects of around 50 mm, made as a two-finger model (50-2) and a three-finger model (50-3). The three-finger model carries a payload of up to 250 g. It is designed for delicate, lightweight items such as small fruit and pralines, and the two-finger model suits oblong items such as waffle cones. The fingers are moulded in one piece from detectable silicone approved for food contact under FDA 21 CFR and EU 1935/2004. The gripper weighs 55 g, operates at a vacuum level of 20 kPa to 60 kPa and mounts on the same fittings as piGRIP suction cups.
Key Specifications
Specification | Piab piSOFTGRIP 50 |
Manufacturer | Piab |
Model | piSOFTGRIP 50 |
Category | End effector / Gripper |
Payload | 0.25 kg |
Certifications | FDA 21 CFR, EU 1935/2004 |
Price | From USD 190 |
Prices are indicative, are not final and may change.
Applications
Robot end-of-arm tooling
Gripping
Machine tending
Assembly
Packaging
Industries
Automotive · Electronics · Metalworking · Plastics · Food and beverage · Pharmaceuticals · Logistics
Technical Details
Vacuum-driven soft gripper
2 fingers (50-2) or 3 fingers (50-3)
Payload up to 250 g (50-3)
Weight 55 g
Operating vacuum 20-60 kPa
Pinch force 3.3 N at 60 kPa
Detectable silicone fingers, Shore A 70
PiGRIP fittings
Piab piSOFTGRIP 50 Review Summary
The Piab piSOFTGRIP 50 is a vacuum-driven soft gripper for objects of around 50 mm, made as a two-finger model (50-2) and a three-finger model (50-3). The three-finger model carries a payload of up to 250 g. It is designed for delicate, lightweight items such as small fruit and pralines, and the two-finger model suits oblong items such as waffle cones. The fingers are moulded in one piece from detectable silicone approved for food contact under FDA 21 CFR and EU 1935/2004. The gripper weighs 55 g, operates at a vacuum level of 20 kPa to 60 kPa and mounts on the same fittings as piGRIP suction cups. It is listed from USD 190.
Pros
Payload: 0.25 kg
Cons
Compatibility with the robot and controller must be confirmed before ordering
Mounting, cabling and integration are quoted separately
Who It Is For
The Piab piSOFTGRIP 50 fits robot users and integrators who need a gripper for handling, machine tending or assembly.
