JAKA Robotics JAKA Zu 5 Overview
The JAKA Zu 5 is a 6-axis collaborative robot with a 5 kg payload, a 954 mm working radius and ±0.02 mm repeatability. It is designed for general-purpose handling, assembly and machine tending at benches and small cells, where its reach of almost one metre covers a full workstation. The arm weighs 23 kg, reaches a maximum TCP speed of 3 m/s and is rated IP54. It can be mounted at any angle and runs on the JAKA StandardCab control cabinet.
Key Specifications
Specification | JAKA Robotics JAKA Zu 5 |
Manufacturer | JAKA Robotics |
Model | JAKA Zu 5 |
Category | Robot arm / Collaborative robot |
Payload | 5 kg |
Reach | 954 mm |
Repeatability | ±0.02 mm |
Speed | 3 m/s |
Axes (DoF) | 6 |
Controller | JAKA StandardCab control cabinet |
Interfaces | TCP/IP; Modbus TCP; Modbus RTU; PROFINET; EtherNet/IP; 16 digital inputs; 16 digital outputs; 2 analog inputs or outputs |
Price | From USD 18,600 |
Prices are indicative, are not final and may change.
Applications
Machine tending
Packaging
Inspection
Assembly
Dispensing
Industries
Automotive · Electronics · Metalworking · Plastics · Food and beverage · Pharmaceuticals · Logistics
Technical Details
6 axes
Payload 5 kg
Working radius 954 mm
Repeatability ±0.02 mm
Weight 23 kg
Max. TCP speed 3 m/s
IP54
Mounting any angle
Control cabinet IP44, 16 DI / 16 DO
JAKA Robotics JAKA Zu 5 Review Summary
The JAKA Zu 5 is a 6-axis collaborative robot with a 5 kg payload, a 954 mm working radius and ±0.02 mm repeatability. It is designed for general-purpose handling, assembly and machine tending at benches and small cells, where its reach of almost one metre covers a full workstation. The arm weighs 23 kg, reaches a maximum TCP speed of 3 m/s and is rated IP54. It can be mounted at any angle and runs on the JAKA StandardCab control cabinet. It is listed from USD 18,600.
Pros
5 kg maximum payload with a 954 mm reach
±0.02 mm repeatability
Speed: 3 m/s
Collaborative design for work near people, subject to a risk assessment
Wide choice of communication interfaces
Graphical programming environment
Cons
The 5 kg maximum payload includes the end effector
End effectors, safety equipment and integration are quoted separately
Who It Is For
The JAKA Zu 5 fits manufacturers that want a robot working near people without full fencing, subject to a risk assessment.
