Teledyne DALSA Falcon4-CLHS Overview
Teledyne DALSA Falcon4-CLHS is a high-speed area-scan family using Camera Link HS. Current model tables differ from older catalog examples. Select the exact camera and receiving configuration rather than combining resolution and speed from different models.
Key Specifications
Product detail | Specification |
Product | Teledyne DALSA Falcon4-CLHS |
Image format | Model-specific area image; select the exact ordering code |
Acquisition | Global |
Interface | Camera Link HS; exact model and receiving configuration |
Capture rate | Model-specific; no single family-wide operating point |
Camera type | High-speed CMOS area-scan family |
Interface | Camera Link HS |
Review Summary
The family merits evaluation when the required field and cadence justify a high-bandwidth acquisition system. Its useful advantage is a documented coherent image-and-rate configuration. The receiver, host processing and retained data must support the same requirement. A fast acquisition demonstration is not evidence that a complete inspection finishes at that cadence.
Integration and Selection
The current manufacturer table pairs M2240 with up to 1200 fps, M4480 with up to 600 fps and M8200 with up to 90 fps. These are separate model operating points. Some overview text retains different historical figures, so obtain the exact ordering-code datasheet and operating mode. Validate Camera Link HS receiving and processing under sustained load, including any multi-board arrangement.
Price: Request a quote.
