Nanotec PD6-E and PD6-EB Integrated Motors
Nanotec PD6 integrates motor, controller/drive and encoder into a compact assembly. The PD6-E stepper and PD6-EB brushless motor are different designs: the cited 10 Nm holding torque and 942 W rated power belong to different configurations, not one universal integrated motor.
Key Specifications
PD6-EB source configuration | 80 mm flange; rated power up to 942 W |
PD6-E source configuration | 86 mm / NEMA 34 flange; holding torque up to 10 Nm |
Integrated elements | Motor, controller/drive and encoder |
Multiturn feedback | Available configuration option; not universal |
Control choices | Fieldbus, clock/direction or I/O by model; integrated sequence control supports stand-alone use |
Engineering | Plug & Drive Studio parameterization/programming |
Price | Request a quote for exact motor, network and feedback configuration |
Applications and Industries
Integrated OEM motion axes where local motor control and an explicit network/feedback configuration reduce installation effort.
Industrial automation
Review Summary
Consider PD6 when local integrated control suits the machine and the exact motor/network version meets the load duty. Specify the actual winding, feedback, fieldbus and mechanical interface together. Multiturn feedback is an option to verify, rather than a feature to assume from a general product heading.
Price and Configuration
Request a quote for the selected configuration,quantity and delivery schedule. Confirm the exact model,options,integration scope and support terms.
