Iris Dynamics RAVEN-6DoF Motion Platform Development Kit
RAVEN-6DoF is a development kit for custom Stewart motion platforms, combining six ORCA intelligent linear motors, a SuperEagle controller, kinematic software and reference design information. It is not a fully manufactured ride or a complete simulation application. The current manufacturer page specifies 230 mm actuator stroke;older material in the supplied listing describes 300 mm, so the ordered motor and reference revision must govern.
Key Specifications
Kit hardware | Six ORCA-15-48V intelligent linear motors;SuperEagle controller |
Software/design | Kinematics, reference CAD and bill of materials |
Current stroke headline | 230 mm;confirm ordered motor/reference revision |
Power architecture | Specified 48 V DC battery arrangement |
Payload scope | Up to 350 kg in the defined supported design |
Mechanical scope | Custom base/top geometry;reference pneumatic offset system |
Supply boundary | Platform manufacture and application simulation software are separate |
Applications and Industries
Simulation, training, teleoperation and immersive-motion development using a custom engineered Stewart platform.
Simulation and training; Virtual reality; Teleoperation
Review Summary
Consider RAVEN when the project needs a custom six-degree-of-freedom geometry and has engineering capacity for the completed platform. The 350 kg payload headline belongs to the defined mechanical/pneumatic design and operating envelope. It is not a guarantee of 350 kg at every pose, acceleration and geometry.
Price and Configuration
Request a quote for the selected configuration,quantity and delivery schedule. Confirm the exact model,options,integration scope and support terms.
