Jenny Science ROTAX Rxhq and Rxvp Rotary Axes
Jenny Science ROTAX Rxhq and Rxvp Rotary Axes
ROTAX provides direct-drive rotary axes with absolute measurement and selected hollow-shaft or fluid-feedthrough arrangements. Rxhq 50 and Rxhq 110 are different frame classes; the current 110-50T4.0 data identify a 50 mm hollow shaft and 4.0 N·m nominal torque. The smaller 110-50T1.5 and special Rxvp have separate functions and limits.
Review Summary
Consider ROTAX where a compact direct drive and central routing fit the process. Select motor, encoder resolution, cable and XENAX control scope together. The source’s 4.5 N·m family statement should not replace the current 4.0 N·m nominal rating of the identifiedT4.0 configuration.
Rxhq 110-50T4.0 nominal torque 4.0 N·m under stated continuous conditions T4.0 peak torque 12.0 N·m at documented 10% peak-duty scope T4.0 hollow shaft 50 mm T4.0 feedback choices 648000 or 2592000 increments/revolution;different repeatability/speed scope Current high-resolution example ±1 arcsec bidirectional repeatability;not universal accuracy Rxhq 50 /110-T1.5 Separate smaller/torque configurations;use respective data Rxvp Distinct compressed-air/vacuum feedthrough axis with selected ELAX integration Applications and Industries
Compact precision rotary positioning, inspection and supported pick-and-place axis combinations.
Industrial automation
Request a quote for the exact configuration,quantity and delivery schedule.
| Rxhq 110-50T4.0 nominal torque | 4.0 N·m under stated continuous conditions |
| T4.0 peak torque | 12.0 N·m at documented 10% peak-duty scope |
| T4.0 hollow shaft | 50 mm |
| T4.0 feedback choices | 648000 or 2592000 increments/revolution;different repeatability/speed scope |
| Current high-resolution example | ±1 arcsec bidirectional repeatability;not universal accuracy |
| Rxhq 50 /110-T1.5 | Separate smaller/torque configurations;use respective data |
| Rxvp | Distinct compressed-air/vacuum feedthrough axis with selected ELAX integration |
