ATS SuperTrak HORIZON10
The ATS SuperTrak HORIZON10 is an intelligent linear motor conveyance platform with independent shuttles carrying 10 kg, 154 mm pitch, ±0.01 mm repeatability, speeds up to 4 m/s, systems up to 64 m and 500 mm, 800 mm or 90° curves.
HORIZON10 carries up to 10 kg per shuttle at a 154 mm pitch, with the same ±0.01 mm repeatability and up to 4 m/s speed as the rest of the range. Systems run up to 64 m, and curve options of 500 mm, 800 mm or 90° give more layout freedom than the smaller HORIZON3. Independent shuttle control lets each product dwell at stations, queue or bypass, replacing indexing conveyors. It is clean room rated and configured with TrakMaster.
Pricing is available on request. Any price is indicative only, is not final and may change; contact us for a confirmed quote.
Full review: ATS SuperTrak HORIZON10 Review: Specs and Uses of the 10 kg Smart Linear Conveyor
- Payload per shuttle: 10 kg
- Shuttle pitch: 154 mm
- Repeatability: ±0.01 mm (straight sections)
- Max speed: Up to 4 m/s
- Max system length: 64 m
- Curves: 500 mm, 800 mm, 90°
- Environment: Clean room
- Software: TrakMaster
- Price: Price on request
