ABB Robotics IRB 5500
The ABB IRB 5500 FlexPainter is a paint robot with a 13 kg payload, a 2970 mm reach and a position repeatability of ±0.15 mm. It is an explosion-protected arm for exterior painting of car bodies and other large parts, built with six axes or with a seventh axis for rail travel. The robot can be floor, wall, inverted or tilted mounted, is rated IP66 and runs on the IRC5P paint controller.
The price shown is indicative only. It is not final and may change; contact us for a confirmed quote.
- Payload: 13 kg
- Reach: 2970 mm
- Repeatability: ±0.15 mm
- Axes: 6 or 7
- Controller: ABB IRC5P
- Interfaces: Interbus-S; PROFIBUS; PROFINET; CC-Link; DeviceNet; EtherNet/IP; Ethernet; USB; analog, digital and relay I/O
- Certifications: ATEX II 2 G Ex ib px IIB T4; ATEX II 2 D Ex pD 21 T65°C; FM Class I, II Div. 1 Groups C, D, G
- Details: 6 or 7 axes; max. payload 13 kg; reach 2970 mm; repeatability ±0.15 mm; mounting floor, wall, inverted, tilted or rail; protection IP66, explosion protected; controller IRC5P.
