Kawasaki CX165L Review: Specs, Price and Applications of the 165 kg Industrial Robot
Updated: 2 days ago
The Kawasaki CX165L is a 6-axis industrial robot with a maximum payload of 165 kg, a reach of 2699 mm and ±0.2 mm repeatability, listed from USD 62,000. This review covers its full specifications, design, programming options, applications and price, so you can decide whether it fits your automation project.
Quick Verdict
The Kawasaki CX165L is a 6-axis industrial robot with a 165 kg payload, a reach of 2699 mm and a positional repeatability of ±0.2 mm. It is a general-purpose large-payload robot with a lightweight hollow arm, suited to tasks from material handling to spot welding. The robot weighs 870 kg, is floor-mounted and runs on the Kawasaki E02 controller. It is listed from USD 62,000. The CX165L is no longer part of the current Kawasaki product range.
Kawasaki CX165L at a Glance
Maximum payload: 165 kg
Reach: 2699 mm
Axes: 6
Repeatability: ±0.2 mm
Weight: 870 kg
Controller: E02
Price: from USD 62,000
Status: no longer part of the current Kawasaki product range
Kawasaki CX165L Technical Specifications
The table below lists the published specifications of the Kawasaki CX165L.
Specification | Kawasaki CX165L |
Manufacturer | Kawasaki Robotics |
Model | CX165L |
Robot type | 6-axis industrial robot |
Maximum payload | 165 kg |
Reach | 2699 mm |
Axes | 6 |
Repeatability | ±0.2 mm |
Controller | E02 |
Interfaces | Ethernet 100BASE-TX x2, USB x2, RS-232C x2, general-purpose I/O 32 in/32 out, DeviceNet, PROFIBUS-DP, INTERBUS, EtherNet/IP, CC-Link, CC-Link IE, Modbus/TCP, CANopen, PROFINET, EtherCAT |
Certifications | EN ISO 13849-1 Category 4, PL e safety circuit |
Starting price | From USD 62,000 |
Detailed Technical Data
6 axes
Max. payload 165 kg
Reach 2699 mm
Repeatability ±0.2 mm
Mass 870 kg
Mounting floor
Controller E02
Design and Build Quality
The CX165L belongs to the Kawasaki CX series. Published build data: mass 870 kg; mounting floor.
Programming and Software
AS Language and K-ROSET
The CX165L runs on the E02 controller and is programmed from the teach pendant in Kawasaki's AS language. Kawasaki's K-ROSET software is available for offline programming and simulation.
Industrial Communication
Published interfaces are Ethernet 100BASE-TX x2, USB x2, RS-232C x2, general-purpose I/O 32 in/32 out, DeviceNet, PROFIBUS-DP, INTERBUS, EtherNet/IP, CC-Link, CC-Link IE, Modbus/TCP, CANopen, PROFINET and EtherCAT.
Kawasaki CX165L Applications and Use Cases
Typical applications for the CX165L are material handling, machine tending, assembly, packaging, inspection and dispensing.
Material handling
A 165 kg maximum payload and a 2699 mm reach let the CX165L move parts between stations, fixtures and conveyors.
Machine tending
The CX165L loads and unloads machine tools, presses and moulding machines within its 2699 mm reach.
Assembly
Repeatability of ±0.2 mm supports fitting, inserting and fastening parts in assembly cells.
Kawasaki CX165L Price and Value
The Kawasaki CX165L is listed from USD 62,000 on All Things Cobots. The controller, end effectors, safety equipment and integration affect the final price and are quoted separately. Prices are indicative, are not final and may change.
Pros and Cons
Pros
165 kg maximum payload with a 2699 mm reach
±0.2 mm repeatability
Wide choice of industrial fieldbus interfaces
Cons
No longer part of the current Kawasaki product range
Repeatability of ±0.2 mm is wider than on smaller precision robots
Needs safety fencing or equivalent safeguarding
The 165 kg maximum payload includes the end effector
End effectors, safety equipment and integration are quoted separately
Who Should Buy the Kawasaki CX165L?
The Kawasaki CX165L fits manufacturers that need an industrial robot of this size for handling, machine tending and assembly. For a new project, ask Kawasaki for the current equivalent.
See the full Kawasaki CX165L product listing on All Things Cobots.
Kawasaki CX165L FAQ
How much does the Kawasaki CX165L cost?
The Kawasaki CX165L is listed from USD 62,000 on All Things Cobots. The price is indicative and may change, and it does not include end effectors, safety equipment or integration.
What is the payload and reach of the Kawasaki CX165L?
The CX165L has a maximum payload of 165 kg and a reach of 2699 mm.
How accurate is the Kawasaki CX165L?
Its published repeatability is ±0.2 mm.
How many axes does the Kawasaki CX165L have?
The CX165L has 6 axes.
How is the Kawasaki CX165L programmed?
It is programmed from the teach pendant in Kawasaki's AS language, and K-ROSET is available for offline programming and simulation.
Which controller does the Kawasaki CX165L use?
It runs on the E02 controller.
How much does the Kawasaki CX165L weigh?
Published mass 870 kg.
How can the Kawasaki CX165L be mounted?
Published installation options: floor.
Is the Kawasaki CX165L still in production?
No. The CX165L is no longer part of the current Kawasaki product range.
What is the Kawasaki CX165L used for?
Typical applications are material handling, machine tending, assembly, packaging, inspection and dispensing.
Specifications and prices are based on manufacturer and distributor information. Prices are indicative, are not final and may change.
